Traffic Safety Road Line Painting Machine 200Kg Road Marking Paint Machine

Name: Traffic Safety Road Line Painting Machine 200Kg Road Marking Paint Machine
Brand: Safebuild
Price: 1 USD

Quality Traffic Safety Road Line Painting Machine 200Kg Road Marking Paint Machine for sale

Place of Origin : Shandong, China

Brand Name : Safebuild

Certification : ISO900

Packaging Details : Export standard bundle or as clients request

Supply Ability : 600 Set/Sets per Year

Price : $1,800.00/sets 1-19 sets

Applicable Industries : Machinery Repair Shops, Printing Shops, Construction works

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2019

Warranty of core components : 1 Year

Core Components : Engine, Pressure vessel, Gear

Condition : New

Power : 5.5HP/ 15HP

Dimension(L*W*H) : 1200*1200*1200mm

Weight : 200 kg

Features : long lifetime

Warranty : 1 Year

UNIQUE SELLING POINT : Long lifetime

Application : City Road Edge Line

Product Name : Manual Airless Paint Spraying Machine

Line Types : Thermoplastic Line

Usage : Making Marks

Name : Airless Road Line Marker

Marking mode : Traffic Safety Paint

Road marking machine : Hand PushThermoplastic Paint Road Line

Keyword : Road Marker Machine

After Warranty Service : Online support

Port : Qingdao Tianjin Ningbo Shanghai Port, China

Contact Now

Products Description

Traffic Safety Road Line Painting Machine 200Kg Road Marking Paint Machine

Road Marking machine is a road construction machine widely used in roads, high roads, parking lots, squares and runways to mark out different restrictions, guidelines and warnings on the level ground. The marking machine plays a great role in urban planning and highway construction with its advantages of speed, efficiency and accuracy, and saves the time limit and economic investment of road construction to the greatest extent

Details Images

Room temperature hand push road marking machine

This machine is hydraulic plunger variable pump marking machine, hydraulic cylinder is mechanical control automatic reversing device, its working frequency is automatically controlled according to the flow rate of the spray gun. Adopt double section variable pump, the pressure is more stable than gear pump, line painting is more neat, with high efficiency, simple operation, smooth walking characteristics.
Technical parameters:
Engine: Honda 5.5-HP gasoline engine
Oil pump: plunger variable pump
Hydraulic cylinder: Mechanical controlled automatic reversing device
Paint pump: piston type high pressure paint pump
Maximum flow: 8L/min
Maximum pressure: 20Mpa
Working pressure: 15Mpa
Spraying line width: spraying width is 8-45mm
Airbrush: double airbrush, both fixed and hand

Room temperature on-board road marking machine

Microcomputer automatic control, simple operation, dotted line, solid line arbitrary regulation, hydraulic spray gun, quick opening and closing, neat line line, column rotary nozzle, marking speed 6-10km/h, durable equipment, high working efficiency.
Technical parameters:
Engine: Honda 13HP gasoline engine
Hydraulic cylinder: Mechanical controlled automatic reversing device
Paint pump: piston type high pressure paint pump
Maximum flow: 15L/min
Maximum pressure: 25Mpa
Working pressure: 15Mpa
Oil pump: Gear pump
Nozzle: column rotary nozzle, spraying width 8-45mm
Stainless steel drum capacity: 150KG*2

Two-component hand push road marking machine

The machine is A road marking machine with external mixture of A and B components. The two sets of hydraulic cylinders are mechanically controlled automatic reversing devices, whose working frequency is automatically adjusted according to the flow rate of the spray gun. Adopting imported variable pump, the pressure is more stable than gear pump, the line is more neat, with the characteristics of flexible operation, even mixing, smooth walking.
Technical parameters:
Engine: Honda 5.5-HP gasoline engine
Hydraulic drive: Plunger variable pump
Maximum flow: 8L/min
Maximum pressure: 20Mpa
Working pressure: 15Mpa
Double paint bucket: A, B two components are independent, to avoid mixing and solidification in the bucket
Nozzle: Column rotary nozzle
Spraying width: 8-45cm
Airbrush: Double airbrush (two components A and B)

Hot melt push road marking machine
Luxury type, double layer stainless steel insulated bucket, save fuel;
Cemented carbide floor knife can prolong service life and the coating thickness can be adjusted freely.
High temperature resistant soft rubber wheel, durable, smooth walking;
The machine has the characteristics of simple structure, flexible operation, free closing, even coating and neat marking
High construction quality, durable equipment, saving maintenance costs.
Technical parameters:
Paint bucket capacity: 125KG
Heating method: LPG
Line width: 100, 150, 200, 300, 400, 450mm
Coating thickness: 1.5-4mm adjustable
Edge knife material: hard alloy
Bead spreader: automatic glass bead spreader

Hydraulic double cylinder hot melt kettle

The equipment can meet the yellow and white paint construction, with high efficiency, good heat preservation, fuel saving, easy to operate, save maintenance costs and other characteristics
Technical parameters:
Engine: 15HP diesel engine
Motor: Hydraulic motor
Hydraulic oil tank capacity: 90L
Stirring: stepless speed regulation, positive and negative rotation
Paint bucket capacity: 600KG*2
Burner: Direct injection burner with high efficiency
Fuel: LPG/diesel
Bottom of kettle: Thickened flat bottom

Self-propelled oscillating road marking machine
Microcomputer automatic control, easy to operate The drive adopts American hydraulic system, which can travel forward and backward with infinitely variable speed Hopper specifications optional, flexible construction
Simple operation, free closing, neat marking, uniform coating, low labor intensity
Technical parameters:
Engine: Honda 5.5-HP gasoline engine
Walking system: Imported hydraulic system
Linewidth: 150/200/300/400/450mm
Coating thickness: 1.5-4mm adjustable
Raised height: 0-7mm adjustable
Stainless steel drum: 125kg
Heating method: LPG
Edge knife material: hard alloy
